Use D flip-flops to design a mod 5 counter. The counting sequence is 000->010->110->101->111->000...(a) Draw the state diagram using 5 states; (b) Use CBA to represent the three bits of the state and write the state transition table; (c) Use K-maps to derive minimum sum-of-product equations for the flip-flop inputs.
Use D flip-flops to design a mod 5 counter. The counting sequence is 0…
